Modern Carriage House Plan with Loft Apartment
This approximately 1,776-square-foot two-level carriage house combines an oversized two-car garage and workshop below with a bright one-bedroom loft apartment above. Its compact footprint and optional private exterior stair suit guest, rental, studio, or hobby-space uses.
Measurements
1,776 ft²165 m²Total area
1Bedroom
1Bathroom
2Levels
2Garage spaces
One-time payment$9.99Lifetime access included
Unlock 200+ Homeplans200+ Editable HomeplansProfessionally designed starting points
Lifetime AccessPay once and keep the full collection
Edit in 2D and 3DMove walls, update furniture, and change finishes
Fit Your SpaceSet your own dimensions and room sizes
EXPLORE THIS PROJECT
See How Garage and Loft Living Work Together
Explore a generous vehicle and workshop level, dedicated storage rooms, and a self-contained apartment with open living, full kitchen, bedroom, and bath.
Plan Walkthrough
Garage and Workshop Level
The approximately 1,184-square-foot ground floor accommodates two vehicles plus workshop and storage uses, with three dedicated storage rooms for tools and gear.
Loft Living and Kitchen
The approximately 592-square-foot upper apartment centers on an open living and kitchen area beneath consistent 9-foot ceilings.
Bedroom and Bathroom
A separate bedroom and full bathroom provide privacy and make the loft suitable for longer stays or independent occupancy.
Access and Flexibility
An optional private exterior stair can give guests or tenants independent access without passing through the garage.
Full Specifications
Total area1,776 ft²165 m²
Dimensions31' wide × 38' 11" deep9.4 m wide × 11.9 m deep
Bedrooms1
Bathrooms1
Levels2
Garage spaces2
Building height21' 4"6.5 m
Overall Footprint31' x 39'9.4 m x 11.9 m
Garage/Shop (1st Fl.)1,184 ft²110 m²
Loft Living (2nd Fl.)592 ft²55 m²
Ceiling heightConsistent 9' ceilings on both levelsConsistent 2.7 m ceilings on both levels
RoofLow-slope metal roof over simple gable/hip frame
GarageOversized side-by-side garage for 2 vehicles plus shop
Is This Plan Right for You?
Best for
- Homeowners needing garage, workshop, and guest space
- Rental or multigenerational living concepts
- Boat, hobby, or extra-vehicle storage
- Narrow or rear-lot carriage house projects
- Owners seeking a private studio above a garage
Things to consider
- Upper-level living requires stairs
- Garage noise, fumes, fire separation, and ventilation need professional planning
- Exterior access, egress, and utilities may affect local approval
- The apartment is compact despite the large total area
- Verify zoning, structure, fire safety, utilities, and local codes before building
