Retail & Shop-fitting Planner

Shopfitting sales depend on configuration and layout approval

Retail fixtures are rarely simple catalogue items. A shelving run, wall system, counter, or display depends on dimensions, modules, finishes, and accessories — and the configured product still has to work inside the real store.

Flat drawings stall approval

Customers struggle to sign off store concepts from 2D drawings or static PDFs — they can’t picture scale, sightlines, or how fixtures fill the space.

Configuration and layout live in separate tools

Reps configure shelving combinations by hand, then redraw the floor plan elsewhere — so variants get misconfigured and data is re-entered at every step.

Quotes and revisions are slow and manual

Product breakdowns are assembled by hand after the layout is built, and every change means updating both the configuration and the plan twice over.

Planning a retail store layout with Planner 5D

A white-label retail & shopfitting planner, powered by your fixture catalogue

Planner 5D connects product configuration and store layout planning in one workflow. It embeds in your website as a self-serve experience, runs in your team’s sales process, or powers a showroom and project proposal flow — all under your brand, with your real fixtures.

Configure fixtures in 3D

Customers or reps configure shelving bays, wall systems, counters, storage, and displays — rule-based logic guides valid dimensions, modules, finishes, and accessories.

Place them into the real store, in 2D and 3D

Configured products drop into the store floor plan to review scale, sightlines, aisle width, fixture density, and customer flow in context.

Self-serve or sales-assisted

Customers spec smaller fit-outs on their own; your team co-designs high-value store projects live — no CAD specialist required for every proposal.

Planner 5D shopfitting planner showing a 2D plan and 3D view

Quote-ready as the layout takes shape

Every configured fixture is captured as the layout is built. The finished project goes to your team or system as a ready-to-quote shopfit — store layout, configured products, SKUs, quantities, finishes, and total value attached.

Layout, plan & 3D visuals

The store layout, 2D plan, and 3D view of the agreed fit-out.

Configured products & SKUs

Selected fixtures, configured options, quantities, and SKUs — built automatically during layout.

Handoff & next step

Project context plus output to CRM, ERP, quote, order, or CAD export.

Submitted shopfit projectREADY TO QUOTE

Convenience store fit-out

180m² · 2D/3D · gondola shelving · wall systems · checkout counters · refrigeration · displays

Layout

Convenience · 180m²

Fixtures

Shelving, counters, fridges

Products

SKUs, configs, quantities

Handoff

Quote, CRM, ERP, or CAD

Common use cases

Shopfitting companies, retail fixture suppliers, and display brands use Planner 5D for fixture configuration, sales proposals, and multi-site store rollout.

Shelving & wall-system brands

Configurable fixture systems

Configure shelving runs, bay counts, heights, depths, finishes, and accessories with rule-based logic — then place the final setup into a store layout to show how it works in context.

3D configuratorRule-based logicStore layout

Shopfitting sales & display teams

Shopfitting sales tool

Sales reps create visual retail layouts with configured fixtures and quote-ready product data — without waiting on CAD support for every early-stage proposal.

Visual proposalQuote outputNo CAD required

Retail chains & multi-site operators

Store concept rollout

Create reusable store templates and fixture layouts that adapt across locations, regions, and formats — keeping fixture standards consistent without starting from scratch.

Store templatesMulti-locationLayout reuse

Explore a sample shopfit project

A finished store layout built in the planner — spin the 3D view and explore the fixtures. In your deployment, your own catalogue and branding replace the defaults.

Sample shopfit project — 3D view

your branding replaces the defaults

Open this page on desktop

The interactive 3D view needs a larger screen. Please open this page on a desktop to explore the sample project.

Key capabilities

Everything needed to connect fixture configuration, retail layout planning, and quoting in one workflow.

White-label 2D/3D retail planner

Embedded on your site or sales portal with your branding, fixture catalogue, and workflow.

3D fixture configurator

Shelving, wall systems, counters, and displays configured with rule-based logic before placement.

Custom 3D fixture catalogue

Your shelving, displays, cabinets, refrigeration, and equipment — with SKUs and product data.

CRM, ERP & quoting integration

Product lists, configured specs, and project data flow to your CRM, ERP, or quote workflow.

AI floor-plan recognition

Upload a store floor plan and AI converts it to an editable, dimension-accurate 3D layout in seconds.

4K renders & CAD export

Photorealistic visuals for proposals, plus CAD export (IFC/DWG/DXF) for contractor and production handoff.

What to measure from day one

Define success metrics before launch so the planner can be judged as an approval, efficiency, and commercial channel.

Faster design approval

Interactive 2D/3D proposals reduce the back-and-forth before customers sign off a store concept.

→ Track: revisions per project, time to approval

Configuration accuracy

Rule-based configuration reduces invalid or incomplete shelving and fixture specifications.

→ Track: spec errors, misconfigured orders

Proposal turnaround time

Configured layouts shorten the path from customer brief to a priced, product-listed proposal.

→ Track: time from enquiry to proposal sent

Fewer redraws & errors

Clearer visualisation and carried-through data cut late-stage changes and fulfilment issues.

→ Track: rework rate, fulfilment corrections

Want this modelled on your numbers? Ask for the ROI estimate in your demo.

Built to sell, not just to draw

Most shopfitting teams already have CAD. The problem was never drawing — it’s turning a drawing into an approved, priced fit-out. Here is how the two compare.

Comparison

CAD & separate toolsAutoCAD, SketchUp, manual quoting

Planner 5D for Businessthe selling difference

Licensing & cost

CAD & separate toolsPriced per seat. Cost scales with every person who needs access.

Planner 5DPlatform license, unlimited users. Your whole sales team or thousands of visitors — same price.

Who can use it

CAD & separate toolsSpecialist-dependent. Usually only 1–2 trained people.

Planner 5DAnyone can use it. Consumer-grade UX — sales reps and your customers can use it too.

Configuration & layout

CAD & separate toolsTwo separate workflows. Fixtures configured by hand, then redrawn in the plan.

Planner 5DOne connected flow. Configure, place, and price in a single session — data carries through.

Final output

CAD & separate toolsA drawing. Quoting is a separate manual step afterward.

Planner 5DFloor plan to priced shopfit proposal in one session. The design becomes the sale.

Integration & output

CAD & separate toolsStandalone. Exports drawings; no cart, CRM, or ERP.

Planner 5DConnected to where you make money. Pushes to quote / CRM / ERP and still exports to CAD (IFC/DWG/DXF).

Frequently asked questions

What is a 3D shopfitting planner?

A 3D shopfitting planner lets sales teams or customers configure store fixtures, place them into a retail layout, and review the setup in 2D and 3D before quoting. Planner 5D adds your own fixture catalogue, configuration logic, and CRM, ERP, or quote connectivity — so a store layout becomes a priced, ready-to-quote product list.

Can Planner 5D configure shelving and retail fixtures?

Yes. Planner 5D supports configurable shelving, wall systems, counters, storage units, displays, and other modular retail fixtures. Rule-based logic controls valid dimensions, modules, finishes, and accessories before the product is placed into the layout.

Can configured fixtures be added to a store layout?

Yes. Configured products are placed into a 2D/3D retail layout so customers or sales teams can see how they fit in the full store plan, including scale, sightlines, aisle width, and fixture density.

Can Planner 5D use our own retail fixture catalogue?

Yes. Planner 5D for Business is set up with your custom 3D catalogue — shelving, displays, counters, cabinets, refrigeration units, and other products — including SKUs, pricing, and branding.

Can sales teams use it without CAD skills?

Yes. Planner 5D is designed for commercial teams to create visual layouts without relying on CAD specialists for every early-stage proposal. Reps can build and share a complete shopfitting proposal directly from the tool.

Can it generate product lists and export to CAD?

Yes. Layouts generate configured product specifications, quantities, SKUs, and project data for quoting, CRM, ERP, or order workflows. CAD export (IFC/DWG/DXF) supports downstream handoff when contractors or engineers continue the work.

Sell the complete store fit-out, not just the fixtures
